Roof Tiles Series Cold Roll Forming Machine with Fixed Positon Driven Forming Stations

China Roof  Tiles Series Cold Roll Forming Machine with Fixed Positon Driven Forming Stations supplier
Roof  Tiles Series Cold Roll Forming Machine with Fixed Positon Driven Forming Stations supplier Roof  Tiles Series Cold Roll Forming Machine with Fixed Positon Driven Forming Stations supplier Roof  Tiles Series Cold Roll Forming Machine with Fixed Positon Driven Forming Stations supplier Roof  Tiles Series Cold Roll Forming Machine with Fixed Positon Driven Forming Stations supplier Roof  Tiles Series Cold Roll Forming Machine with Fixed Positon Driven Forming Stations supplier Roof  Tiles Series Cold Roll Forming Machine with Fixed Positon Driven Forming Stations supplier Roof  Tiles Series Cold Roll Forming Machine with Fixed Positon Driven Forming Stations supplier

Large Image :  Roof Tiles Series Cold Roll Forming Machine with Fixed Positon Driven Forming Stations

Product Details:

Place of Origin: Jiangsu, China
Brand Name: Shenghong
Certification: CE ISO
Model Number: Roof Tile SWL151211-29

Payment & Shipping Terms:

Minimum Order Quantity: 1 sets
Price: Negotiation
Packaging Details: 1. Export standard package for container 2. Host nude, wheels with oil and gas bubble cushion packaging. 3. PLC controller with bubble cushion packaging 4. Spare parts in wooden cases.
Delivery Time: 40 days after payment
Payment Terms: T/T
Supply Ability: 30 SETS/ MONTH
Contact Now
Detailed Product Description
Condition: New Certificate: CE, ISO, AAA Credit
Machine Type: Roof Tile Machine After Sales Service: Engineers Available To Service Machinery Overseas
Tile Type: Glazed Steel Number Of Rollers: Depends On Drawings

Roof  Tiles Series Cold Roll Forming Machine with Fixed Positon Driven Forming Stations



Glazed Roof  Roll Forming Machine Introduction

Roof tile series modular tile sheet roll forming machine consists of uncoiler and its base, infeed guides, fixed position driven forming stations, pressing die, shearing device, hydraulic station, PLC control console and so on. Our company has dozens of profile models for this series roll forming machine, such as TM25-183-1100, TM28-207-828, and etc. We can design different kinds of profile and fittings for machine, as per customers' requirements.

The archaistic tile sheet is rolled and pressed by the roof tile series modular tile sheet roll forming machine, it has many features, such as good appearance, primitive simplicity and elegance, unique style, noblest grade, and etc. It is widely used in garden style factories, scenic resorts, pavilions, hotels, villas, exhibition halls, country clubs, and so on for outdoor decorations.


Quick Details

  • Dimension(L*W*H):8000mmX1300mmX1200mm
  • Weight: 7 ton
  • Certification: CE & BV
  • Warranty: 12 months
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Color: As your requirements
  • Cutting type: hydraulic cutting
  • Hydraulic Power: 3 kw
  • Control: PLC control system
  • Raw material : color steel, galvanized steel
  • Thickness: 0.4-0.8mm
  • Shaft diameter : 76mm
  • ODM : Available
  • OEM : We can product as your requirements
  • Production :  Roof Tile Making Machine
  • Condition: New
  • Type: Tile Forming Machine
  • Tile Type: Steel
  • Use: Roof
  • Production Capacity: 10-15m/min
  • Place of Origin: Jiangsu, China (Mainland)
  • Brand Name: Shenghong
  • Model Number: Glazed roof tile
  • Power(W): 5.5KW
  • Voltage: 380V 50HZ 3PH
  •

Technical Parameters



1) automatic inner tight decoiler
    A. Coil inner diameter: 450mm-700mm
    B. Max width of coiling: 1200mm
    C. Max weight of loading: 6000kg
    D.Thickness:0.3-0.7mm



2) Main forming machine
    A. Number of forming steps: according to the profile drawings
    B. Material of shaft : 45# steel adjustable treatment. Outer diameter: 70mm
    C. Material of roller : High grade 45# steel(plated chrome on surface)
    D. Main motor power : 7.5kw
    E. Forming speed : 10-16m/min
    F. Stand : 350# steel welding
    G. The plating chromium of roller surface : 0.05mm



3) hydraulic cutter
    A. Material of blade: Cr12 with quenched treatment60-62º C
    B. Cutting system: Adopt advanced hydraulic drive, automatic cut after forming, no distortion, no waste, high safe factor and then cuts



Working flow



    Decoiling--active feeding--roll forming--measuring length-- cutting to length--product to stand



 Machinery Shows

Roof  Tiles Series Cold Roll Forming Machine with Fixed Positon Driven Forming Stations







 Finished Products in Sample Room
Roof  Tiles Series Cold Roll Forming Machine with Fixed Positon Driven Forming Stations
