Custom Metal Roof Roll Forming Machine With 10 - 12m / Min Forming Speed

China Custom Metal Roof Roll Forming Machine With 10 - 12m / Min Forming Speed supplier
Custom Metal Roof Roll Forming Machine With 10 - 12m / Min Forming Speed supplier Custom Metal Roof Roll Forming Machine With 10 - 12m / Min Forming Speed supplier Custom Metal Roof Roll Forming Machine With 10 - 12m / Min Forming Speed supplier Custom Metal Roof Roll Forming Machine With 10 - 12m / Min Forming Speed supplier Custom Metal Roof Roll Forming Machine With 10 - 12m / Min Forming Speed supplier Custom Metal Roof Roll Forming Machine With 10 - 12m / Min Forming Speed supplier

Large Image :  Custom Metal Roof Roll Forming Machine With 10 - 12m / Min Forming Speed

Product Details:

Place of Origin: Jiangsu, China
Brand Name: Shenghong
Certification: CE ISO
Model Number: Roof Tile SWL151218-55

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: 1. Export standard package for container 2. Host nude, wheels with oil and gas bubble cushion packaging. 3. PLC controller with bubble cushion packaging 4. Spare parts in wooden cases.
Delivery Time: 40 days after payment
Payment Terms: T/T
Supply Ability: 25 SETS/ MONTH
Contact Now
Detailed Product Description
Series: Custom Roofing Sheet Metal Cold Roll Forming Machine Condition: New
Weight: 10 Tons Controls: PLC
Material: Galvanized Or Pre-painted Steel Sheet Hydraulic Pressure: 10 - 12MPa
Quantity Of Stands: About 18 Groups Forming Speed: 10 - 12m/min

Custom Metal Roof Roll Forming Machine With 10 - 12m / Min Forming Speed



Quick Details

  • Place of Origin: China
  • Brand Name: Wuxi Shenghong
  • Certification: CE

Specifications



Our company is a professional supplier in the field of steel structure construction, especially good at making forming machine.

Model SWL151218-55 forming machine consists of uncoiler and its base, coil sheet
guiding equipment, film covered device, roll forming system, post-cutting equipment,
hydraulic station, controlling system, supporter table.

Technical parameters:
1) Material spec: colored steel sheet; galvanized steel sheet
2) Thickness of coil sheet: 0.3 - 0.7 mm
3) Main motor power: 7.5kW
4) Forming speed: 10 - 12m/min
5) Hydraulic station power: 3kW
6) Quantity of stands: about 18 groups
7) Hydraulic pressure: 10 - 12MPa
8) Controlling system: PLC
9) Index error of length: 10m±2mm
10) Total weight: about 1,000kg
11) Voltage: 380V 3 phase 60Hz or at buyer's requirement

Material of main equipment
1) Roller material: high grade no. 45 forged steel, plated hard chrome on the surface
of roller with thickness 0.05mm
2) Active shaft material: high grade No.45 carbon wrought steel at diameter 75mm
3) Cutter blade: Cr12 mould steel with quenched treatment
4) Electric elements: control system with PLC model S7-200, Siemens transducer with
ABB control panel with TP170, Siemens. It can input 10 sets of spec at one time

5) Oil tank model of hydraulic system: CB-E310





Cold Rolling Mills introduction

  1.  Feeding section with guide;
  2.  Gear/Sprocket driving;23-step to form
  3.  Rollers manufactured from 40Cr, CNC lathes, hard Chrome Coated
  4.  Shafts Diameter=75mm, Precision Machined
  5.  Main motor =7.5 KW, Frequency speed control
  6.  Forming speed:Approx. 15m/min;
  7.  Protection Mesh Cover (full mesh type) Above Roll-former To Avoid Hands Go Inside



Hydraulic Cutting Device

  1. Stop to cut, Post cut, No Blanking cut
  2. Pump motor =4.0KW
  3. Cutting tool material : Cr12, Heat treatment;



PLC Control System

  1. Control the quantity & cutting length automatically;
  2. Combined with: PLC, Touch Screen (SIEMENS), Inverter (SCHNEIDER), Encoder (Omron), etc
  3. Cut-to-length tolerance≤±2 mm
  4. Control Voltage 24V
  5. Product Rack      Un-powered, 3 units



Machine Shows

Custom Metal Roof Roll Forming Machine With 10 - 12m / Min Forming Speed



Final Products Showroom



Custom Metal Roof Roll Forming Machine With 10 - 12m / Min Forming Speed
