Corrugared Two Layer Sheet Metal Roll Forming Machines with Coining Process

China Corrugared Two Layer Sheet Metal Roll Forming Machines with Coining Process supplier
Corrugared Two Layer Sheet Metal Roll Forming Machines with Coining Process supplier Corrugared Two Layer Sheet Metal Roll Forming Machines with Coining Process supplier Corrugared Two Layer Sheet Metal Roll Forming Machines with Coining Process supplier Corrugared Two Layer Sheet Metal Roll Forming Machines with Coining Process supplier Corrugared Two Layer Sheet Metal Roll Forming Machines with Coining Process supplier Corrugared Two Layer Sheet Metal Roll Forming Machines with Coining Process supplier

Large Image :  Corrugared Two Layer Sheet Metal Roll Forming Machines with Coining Process

Product Details:

Place of Origin: Jiangsu, China
Brand Name: Shenghong
Certification: CE ISO
Model Number: Roof Tile SWL151218-67

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: 1. Export standard package for container 2. Host nude, wheels with oil and gas bubble cushion packaging. 3. PLC controller with bubble cushion packaging 4. Spare parts in wooden cases.
Delivery Time: 40 days after payment
Payment Terms: T/T
Supply Ability: 25 SETS/ MONTH
Contact Now
Detailed Product Description
Rolling Forming Speed: 12 M / Minute. Cutting Tolerance: +/-2.5mm(length≤5000mm); +/-3.0mm(5000mm
Feeding Width: 1200mm Cover Width: 780mm
Coil Inner Diameter: 508mm. Electric Elements: PLC Control Panel, Transducer Imported From Mitsubishi Of Japan

Corrugared Two Layer Sheet Metal Roll Forming Machines with Coining Process



Roll Forming Machine Introduction



Wuxi Shenghong Machinery colored steel tile forming machine consists of uncoiler and its base, coil sheet guiding equipment, film covered device, roll forming system, pressing equipment, post-cutting equipment, hydraulic station, controlling system, supporter table.



Roll Forming Machine Working Flow:

Decoiling the Sheet→Sheet Guiding→Film Covering→Roll Forming→Measure Lengh → Cutting the sheet→sheet to the Supporter.



Tile Roll Forming Machine Technical Parameters



1)Material Spec:

colored and galvanized steel sheet at yield stress 33 KSI;

2)Thickness of Coil Sheet:

0.5 --0.6 mm

3)Coil Width:

1000mm

4)Working Speed:

2.0 ~ 3.0 m/min. (step distance  at 380mm,)

5)Power Requirement:

main motor power 7.5 kw

6)Hydraulic Station Power:

5.5 kw

7)Passive Uncoiler:

max. Capacity 5000kgs

8)Quantity of Stands:

15 groups or according to profiles

9)Controlling System:

PLC

10)Type of Cutting:

roll-formed and length-set cutting

11)Machine Dimension:

about 18500×1500×1400mm

12)Total Weight:

about 9500kg

13)Voltage:

380V 3 phase 60Hz or at buyer's requirement

































Roll Forming Machine Machine Features



1. Precise forming

2. High-solid forming stand guarantees the good and uniform high quality of final products

3. The operation automatically minimizes the tolerance of cutting length.

Products Features:

1. A stylish and attractive design,giving the apperance of a traditional roof tile.

2. Resistant to frost,heat,hail and gales;100% waterproof, due to the lateral run-off channel on each sheet for several models.

3. The raw material can be in different color, with elegant and noble looking. It is widely used as the garden like factory.



3. Material of Main Equipment



Roller Material

High grade No.45 forged steel, coated with hard chrome.

Active Shaft Material

High grade No.45 carbon wrought steel,which can improve the integrated mechanic feature of the shaft.

Electric Elements

PLC control panel, transducer imported from Mitsubishi of Japan.

Other elements are from famous suppliers of China.

Cutter blades

Cr12 mould steel with quenched treatment.



Machinery Shows



Corrugared Two Layer Sheet Metal Roll Forming Machines with Coining Process



Workshop Show

Corrugared Two Layer Sheet Metal Roll Forming Machines with Coining Process
