Place of Origin: | Jiangsu, China |
---|---|
Brand Name: | Shenghong |
Certification: | CE ISO |
Model Number: | SWL151224-170 |
Minimum Order Quantity: | 1 sets |
Price: | Negotiation |
Packaging Details: | 1. Export standard package for container 2. Host nude, wheels with oil and gas bubble cushion packaging. 3. PLC controller with bubble cushion packaging 4. Spare parts in wooden cases. |
Delivery Time: | 40 days after payment |
Payment Terms: | T/T |
Supply Ability: | 25 SETS/ MONTH |
Power Source: | Electric | Hydraulic Decoiler: | 5-8 Tons |
---|---|---|---|
Type: | Roofing & Cladding Production Lines | Machine: | Roof Wall Panel Cold Roll Forming Machine |
Working Speed:: | 12-15m/min | Hydraulic Pressure:: | 10-12Mpa |
High Light: | roof sheet roll forming machine,roof tile roll forming machine |
Trapezoidal Roof Wall Panel Cold Roll Forming Machine PLC Controlling
Metal roofing roll forming machine technology specification
Item |
Content |
Raw material thickness |
0.3-0.7mm |
Working speed: |
12-15m/min |
Roll station: |
23 stations |
Hydraulic station power: |
4kw |
Hydraulic pressure: |
10-12Mpa |
Main motor power: |
5.5kw |
Controlling system: |
PLC |
Total weight: |
about 10,000kg |
Size |
10500×1500×1200mm |
Roll forming machine for production the Trapezoidal Roof & Siding Panel
Our manufacturer is Specialist in roll forming machinery design for manufacturing the production of building construction, cover the range for production metal roofing and siding wall, various trapezoidal panel profiles can be custom manufactured. The complete roll forming lines for roofing & cladding lines will be supplied. Steel roofing and steel walls are all manufactured on roll forming machine. We deigned the single, double layer and cassette type trapezoid roof panel production lines according to clients’ request. The special designed ribs on can increase the roof panel intensity too much, to obtain the high quality steel roof & wall cladding panels. Steel structure Roll Forming Machines for the manufacture of Metal Roof sheets and Siding Panel / Siding and metal tile Metal Roofing / Metal Building Industries / Construction profiles / Metal Construction Industry.
Trapezoidal Roof panel roll forming machine Components
This Steel structure Ribbed Roof wall panel forming Machine including Roll-forming tools and other equipment, such as for example: unwinding of many types, feeding, straightening, holes punching and perforation or cutting and final packing. All of this equipment is manufactured to order according to the requirements and concepts of the customer. The normal technology for our steel wall & roof panel roll forming machines is as following,
De-coiling - Coil sheet guiding & feeding - Roll forming - cut to length - stacking production
Metal Roof and Wall Cladding Corrugated Sheets
Machine specification
For information on metal roof sheets profiles by our roll-forming mills, please contact with us!
Machinery Photos
Workshop Show
