Automatic Cold Roll Forming Machine Door Frame Roll Form Machine

China Automatic Cold Roll Forming Machine Door Frame Roll Form Machine supplier
Automatic Cold Roll Forming Machine Door Frame Roll Form Machine supplier Automatic Cold Roll Forming Machine Door Frame Roll Form Machine supplier Automatic Cold Roll Forming Machine Door Frame Roll Form Machine supplier Automatic Cold Roll Forming Machine Door Frame Roll Form Machine supplier Automatic Cold Roll Forming Machine Door Frame Roll Form Machine supplier

Large Image :  Automatic Cold Roll Forming Machine Door Frame Roll Form Machine

Product Details:

Place of Origin: China, Jiangsu
Brand Name: Shenghong
Certification: CE ISO
Model Number: SH16-06-05-04

Payment & Shipping Terms:

Minimum Order Quantity: 1 sets
Price: Negotiation
Packaging Details: Container
Delivery Time: 40 days after payment
Payment Terms: T/T
Supply Ability: 30 SETS/ MONTH
Contact Now
Detailed Product Description
Use: Door Production Capacity: 8-10m/min
Power(W): 15kw Dimension(L*W*H): 6.8*0.8*1.2m
Thickness: 0.8-1.2mm Certification: ISO9001 And CE

Automatic Cold Roll Forming Machine Door Frame Roll Form Machine

Product Description





Drawing for you reference:

Automatic Cold Roll Forming Machine Door Frame Roll Form Machine



Parameters:

Technical Data & Specification
Productivity Door frame as the drawing
Man Power Required One operator with one assinstant
Set Up time 15 mins
Working Hours per Day 8 to 16
Number of Stations 18-24 sets
Thickness 0.3-0.8mm
Main Power 15 KW
Shipment Packing one 40 FT container
Forming Speed 20mtr./min(Not include shear)
Line Direction Left to Right While Facing Operator Panel
Overall Machine Length Required 8.5m
Approximate Machine Height 1.5M







Complete Line Consist Of(working process)
Passive decoiler
Infeeding applicator
Roll forming machine unit
Flying saw shear

Output table



After-sale Serive

The seller take responsibility to installation and commissioning of the equipment and free training. After machine arrive the destination, by the request of the buyer , the seller will provide 1 technical engineer to guide installation and training , and the buyer should give the technical person with full cooperated.
Installation period: about 5 days after the complete preparation by the buyer such as the foundation and all necessary accessories.
Training time: 5 days.
Before departure of the engineers from seller, the buyer should pay for installation and commissioning fee 100$/day to the point account of the seller. The two-way ticket,visa, food, hotel , the translator and insurance are all should provide by buyer with full responsibility.
The seller supply technical data (including forming mould drawing, electrical elements drawing and equipment drawing etc.)
