Highway Guardrail Roll Forming Machine , Crash Barrier Roll Forming Machine

China Highway Guardrail Roll Forming Machine , Crash Barrier Roll Forming Machine supplier
Highway Guardrail Roll Forming Machine , Crash Barrier Roll Forming Machine supplier Highway Guardrail Roll Forming Machine , Crash Barrier Roll Forming Machine supplier Highway Guardrail Roll Forming Machine , Crash Barrier Roll Forming Machine supplier Highway Guardrail Roll Forming Machine , Crash Barrier Roll Forming Machine supplier Highway Guardrail Roll Forming Machine , Crash Barrier Roll Forming Machine supplier Highway Guardrail Roll Forming Machine , Crash Barrier Roll Forming Machine supplier

Large Image :  Highway Guardrail Roll Forming Machine , Crash Barrier Roll Forming Machine

Product Details:

Place of Origin: China
Brand Name: Shenghong
Certification: CE
Model Number: SH-160712-2

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Standard packing
Delivery Time: 60 days
Supply Ability: 20 sets
Contact Now
Detailed Product Description

Highway Guardrail Roll Forming Machine , Crash Barrier Roll Forming Machine

A.Detail Production Description

Highway Guardrail Roll Forming Machine, Crash Barrier Roll Forming Machine

B.Technical Specifications of Highway Guardrail Roll Forming Machine, Crash Barrier Roll Forming Machine

Type 311/508±5mm
Material thickness 3.0-4.0mm
Main motor power 37kw
Forming speed 5m/min
Hydraulic station power 11kw
Forming station 15 stands
Shaft Material and diameter Φ95mm, material is 45# steel
Length of guardrail As your requirement
Way of Drive Gear box
Control system PLC, Panasonic
Total Weight 15 tons
Voltage 380V/ 3phase/ 50 Hz
Size of the machine L*W*H 10 m*2.2m*1.7m
Material of Forming rollers Cr15
Cutting Blade: Cr12Mov



C.Main Components

Manual Decoiler x1 set

Hydraulic punching x1 set

Main roll forming machine x1 set

PLC Control System x1 set

Hydraulic cutting x1 set

Run-out table x1 set



D.Work Flow

Decoiler ---Feeding ---Leveling ---Punching---Roll forming --- Hydraulic cutting---Run-out table— Finish

E.Profile Drawing

Highway Guardrail Roll Forming Machine , Crash Barrier Roll Forming Machine





F.Our Advantage

Good quality and working steady

Long time working life
