CE ISO certification Corrugated Roll Forming Machine Professional

China CE ISO certification Corrugated Roll Forming Machine Professional supplier
CE ISO certification Corrugated Roll Forming Machine Professional supplier CE ISO certification Corrugated Roll Forming Machine Professional supplier CE ISO certification Corrugated Roll Forming Machine Professional supplier CE ISO certification Corrugated Roll Forming Machine Professional supplier CE ISO certification Corrugated Roll Forming Machine Professional supplier CE ISO certification Corrugated Roll Forming Machine Professional supplier

Large Image :  CE ISO certification Corrugated Roll Forming Machine Professional

Product Details:

Place of Origin: Jiangsu, China
Brand Name: Shenghong
Certification: CE ISO
Model Number: SH160514-14

Payment & Shipping Terms:

Minimum Order Quantity: 1 sets
Price: Negotiation
Packaging Details: Pe film
Delivery Time: 40 days after payment
Payment Terms: T/T
Supply Ability: 25 SETS/ MONTH
Contact Now
Detailed Product Description
Production Capacity: 6-8m/min Use: Wall And Roof
Dimension(L*W*H): 1000/1200/1250mm Power(W): 32kw
Control System: Plc The Thickness: 38-298mm

INTRODUCTION:

Specifications

1.meet CE, ISO9001standard
2.control system:PLC
3.automatic and hydraulic
4.good after service
5.rich experience more than 1

MAIN TECHNOLOGY PARAMETERS





1 Main moter power: 32KW


2 out line dimension of machine: 33m*2.5m*2.5m


3 Total weight: 10T


4 Processing speed: 0-5m/min


5 the thickness of upper steell plate: 0.3-0.8mm


6 the feeding width of upper steel plate: 1000/1200/1250mm


7 the thickness of lower steel plate: 0.3-0.8mm


8 the feeding width of lower steel plate: 1000/1200/1250mm


9 sandwich material: EPS/rock wool/PU/glass wool/foam


10 the thickness: 38-298mm


11 the width of stocket board: 950/1150mm


12 the width of H board: 1000/1200mm



13 the whole sandwich panel lien includes load car, up roll forming machine, down roll forming machine,roof corrugated roll forming imachine, roller unit,heat unit, glue nunit,double belt machine, saw belt cutter unit and production table



Material of main equipment:

(1)Roll material:high grade NO.45 forged steel,plate hard chrome on the surface of roller with thickness 0.05mm.



(2)Active shaft material:high grade No.45 carbon wrought steel at diameter 75mm



(3)Cutter blade:Cr12 mould steel with quenched treatment



(4)Producing flow:

Decoiling the sheet—sheet guiding—roll forming—measure length—cutting the panel—panels to the supporter



EPS/rock wool/PU/glass wool/foam sandwich panel roll forming machine factory for sale
