Product Details
Place of Origin: Jiangsu, China
Brand Name: HRF
Payment & Shipping Terms
Price: $35,000.00/sets 1-1 sets
Packaging Details: Standard Packing High speed aluminum cut to length line cut to length line machine steel coil slitting line
Supply Ability: 15 Set/Sets per Month
Cutting Width (mm): |
500 - 1300 Mm |
Material Thickness(mm): |
0.3 - 2 Mm |
Cutting Speed(m/min): |
1 - 100 M/min |
Video Outgoing-inspection: |
Not Available |
Machinery Test Report: |
Not Available |
Marketing Type: |
New Product 2020 |
Warranty Of Core Components: |
1 Year |
Core Components: |
PLC, Engine, Gearbox, Motor, Pressure Vessel |
Coil Weight (T): |
25T |
Leveling Precision(±mm/m): |
0.5 ±mm/m |
Condition: |
New |
Voltage: |
380v |
Rated Power: |
300kw |
Dimension(L*W*H): |
25m*2m*2m |
Weight: |
50000, 50000kgs |
Year: |
2013 |
Key Selling Points: |
High Productivity |
Warranty: |
1 Year |
Applicable Industries: |
Construction Works , Building Material Shops, Machinery Repair Shops |
Showroom Location: |
Canada, Italy |
After-sales Service Provided: |
Engineers Available To Service Machinery Overseas |
Application: |
Cut Coil Into The Sheets |
Power: |
150kw |
Coil Thickness: |
0.3 - 2mm |
Type Of Decoiler: |
Hydraulic Decoiler |
Material: |
Gavanzed Steel And Prepainted Steel Coil |
Function: |
Coil Cuting Intto The Sheets |
Line Speed: |
0--100m/min |
Product Name: |
Aluminum Cut To Length Line Steel Coil Slitting Line |
Cutting Width (mm): |
500 - 1300 Mm |
Material Thickness(mm): |
0.3 - 2 Mm |
Cutting Speed(m/min): |
1 - 100 M/min |
Video Outgoing-inspection: |
Not Available |
Machinery Test Report: |
Not Available |
Marketing Type: |
New Product 2020 |
Warranty Of Core Components: |
1 Year |
Core Components: |
PLC, Engine, Gearbox, Motor, Pressure Vessel |
Coil Weight (T): |
25T |
Leveling Precision(±mm/m): |
0.5 ±mm/m |
Condition: |
New |
Voltage: |
380v |
Rated Power: |
300kw |
Dimension(L*W*H): |
25m*2m*2m |
Weight: |
50000, 50000kgs |
Year: |
2013 |
Key Selling Points: |
High Productivity |
Warranty: |
1 Year |
Applicable Industries: |
Construction Works , Building Material Shops, Machinery Repair Shops |
Showroom Location: |
Canada, Italy |
After-sales Service Provided: |
Engineers Available To Service Machinery Overseas |
Application: |
Cut Coil Into The Sheets |
Power: |
150kw |
Coil Thickness: |
0.3 - 2mm |
Type Of Decoiler: |
Hydraulic Decoiler |
Material: |
Gavanzed Steel And Prepainted Steel Coil |
Function: |
Coil Cuting Intto The Sheets |
Line Speed: |
0--100m/min |
Product Name: |
Aluminum Cut To Length Line Steel Coil Slitting Line |
|
Type
|
3×1600
|
6×2000
|
8×2000
|
10×2200
|
12×2200
|
16×2200
|
20×2500
|
25×2500
|
|
Thickness Range(mm) |
0.3-3
|
1-6
|
2-8
|
2-10
|
3-12
|
4-16
|
6-20
|
8-25
|
|
Width Range(mm) |
1600
|
2000
|
2000
|
2200
|
2200
|
2200
|
2500
|
2500
|
|
Cutting Length(mm) |
300-4000
|
500-6000
|
600-8000
|
600-10000
|
800-12000
|
800-12000
|
800-12000
|
800-12000
|
|
Cutting precision(mm) |
±0.5
|
±0.5
|
±1
|
±1
|
±1
|
±1
|
±1
|
±1
|
|
Roller Numbers |
15
|
15
|
13
|
13
|
11
|
11
|
9
|
9
|
|
Roller Diameter(mm) |
Ф85
|
Ф140
|
Ф155
|
Ф160
|
Ф180
|
Ф200
|
Ф230
|
Ф260
|
|
Product Name
|
0.23~0.3)*1000mm Slitting machine
|
|
Condition
|
new
|
|
Size
|
25m*6m*2m
|
|
Color
|
customized
|
|
Purpose
|
Slitting coils
|
|
Package
|
Standard packing
|
|
MQQ
|
1 set
|
|
Delivery
|
80-100 days
|
|
Shipment
|
Shanghai port
|
|
Payment Mode
|
T/T, L/C
|
|
Payment Condition
|
30% deposit in advance. Balance paid by TT before shipping.
|
|
Supply Capacity
|
3 sets per year
|
